| SPECIFICATIONS |
| CAMERA |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Max. Resolution | 2560 x 1920 |
| Min. Illumination | Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON) |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Day &Night | IR Cut Filter |
| Pan/Tilt | Pan: 0° to 355° , tilt: 0° to 75° |
| LENS |
| Focal Length | Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV | 2.8 mm, horizontal FOV 98.0° , vertical FOV 71.7° , diagonal FOV 127.0°
4 mm, horizontal FOV 75.3° , vertical FOV 55.5° , diagonal FOV 98.2° |
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F2.0 |
| IILLUMINATOR |
| Supplement Light Type | IR |
| Supplement Light Range | Up to 30 m |
| Wavelength | 850 nm |
| VIDEO |
| Main Stream | 50 Hz: 20 fps (2560 1920)
25 fps (2560 1440, 1920 1080, 1280 720)
60 Hz: 20 fps (2560 1920)
30 fps (2560 1440, 1920 1080, 1280 720) |
| Sub-Stream | 50 Hz: 25 fps (1280 720, 640 480, 640 360)
60 Hz: 30 fps (1280 720, 640 480, 640 360) |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main profile |
| Region of Interest (ROI) | 1 fixed region for main stream |
| AUDIO |
| Audio Compression | -UF: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Bit Rate | -UF: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to
64 Kbps (AAC) |
| Audio Sampling Rate | -UF: 8 kHz/16 kHz |
| Environment Noise Filtering | -UF: Yes |
| NETWORK |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™,
SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface, ISAPI |
| User/Host | Up to 32 users. 3 levels: administrator, operator and user
3 user levels: administrator, operator, and user |
| Client | iVMS-4200, Hik-Connect |
| Web Browser | Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+ |
| IMAGE |
| Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client
software or web browser |
| Day/Night Switch | Auto, Schedule, Day, Night |
| Wide Dynamic Range (WDR) | 120 dB |
| Image Enhancement | BLC, 3D DNR |
| INTERFACE |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | -UF: Built-in memory card slot, support microSD card, up to 256 GB |
| Built-in Microphone | -UF: Yes |
| Reset Key | -UF: Yes |
| EVENT |
| Basic Event | Motion detection, video tampering, exception |
| Linkage | Upload to FTP, notify surveillance center, send email |
| GENERAL |
| Power | 12 VDC ±25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W |
| Dimension | 177.6 mm 67.8 mm 66.2 mm (7" 2.7" 2.6") |
| Package Dimension | 216 mm 121 mm 118 mm (8.5" 4.8" 4.6") |
| Weight | Approx. 270 g (0.6 lb.) |
| With Package Weight | Approx. 481 g (1.1 lb.) |
| Storage Conditions | -30 C to 60 C (-22 F to 140 F). Humidity 95% or less (non-condensing) |
Startup and Operating
Conditions | -30 C to 60 C (-22 F to 140 F). Humidity 95% or less (non-condensing) |
| Language | English, Ukrainian |
| General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
